Beam Clamps VBC-3 3 Ton Beam Clamp Vbc Series 120616 - Targa Tools

JET VBC-3 ~ 3 Ton Beam Clamp Vbc Series 120616

by JET
203.60 CAD

Ships in 5 days

3 Ton Beam Clamp - VBC Series

  • Robust, all steel construction
  • Can be adjusted to fit securely on a wide range of flange and beam widths
  • Meets ANSI B30.11 specifications (certificate included)
  • Tested to 125% of rated capacity
  • Built in suspension bar provides ultra-low headroom
  • Extension kits available for use on larger beam widths
  • Part # 120616
    Sold in qty's of 1
    Product type Beam Clamps
    Size 5/8 Inch - 18 NF
  • Rated Capacity : 6,600 lb
  • Rated Flange Width : 3-5/32 – 12-39/64 Inch
  • Maximum A: 13-15/16 Inch
  • Minimum B: 9-1/4 Inch
  • Maximum B: 19-19/64 Inch
  • C: 4-1/16 Inch
  • D: 5/16 Inch
  • E: 10-1/4 Inch
  • Maximum F: 5-1/2 Inch
  • Minimum F: 8-55/64 Inch
  • G: 1-49/64 Inch
  • H: 61/64 Inch
