JET VBC-2 ~ 2 Ton Beam Clamp Vbc Series 120615

by JET
126.16 CAD

Ships in 5 days

2 Ton Beam Clamp - VBC Series

  • Robust, all steel construction
  • Can be adjusted to fit securely on a wide range of flange and beam widths
  • Meets ANSI B30.11 specifications (certificate included)
  • Tested to 125% of rated capacity
  • Built in suspension bar provides ultra-low headroom
  • Extension kits available for use on larger beam widths
  • Part # 120615
    Sold in qty's of 1
    Product type Beam Clamps
    Size 5mm - 0.80
  • Rated Capacity : 4,400 lb
  • Rated Flange Width : 2-61/64 – 8-21/32 Inch
  • Maximum A: 10-1/4 Inch
  • Minimum B: 7-3/32 Inch
  • Maximum B: 14-11/64 Inch
  • C: 2-29/32 Inch
  • D: 1/2 Inch
  • E: 8-15/32 Inch
  • Maximum F: 4-1/64 Inch
  • Minimum F: 6-3/32 Inch
  • G: 63/64 Inch
  • H: 7/8 Inch
