Chain Hoists KCH-5020 5 Ton 20' Lift Kch Series Chain Hoist Heavy Duty 101156 - Targa Tools

JET KCH-5020 ~ 5 Ton 20' Lift Kch Series Chain Hoist Heavy Duty 101156

by JET
2,062.73 CAD

Ships in 5 days

5 Ton 20' Lift KCH Series Chain Hoist - Heavy Duty

  • Triple spur geared for efficient operation
  • Maintenance free sealed bearings reduce operator effort
  • Dual pawl Weston style brake with extra heavy pawl springs for safe reliable operation
  • Extra thick ratchet gear protects brake disc from contamination
  • Exclusive premium grade, non-asbestos brake discs for longest life
  • Grade 100 load chain for greater strength
  • Top and bottom safety hooks bend slowly to warn of overloads
  • Cast safety latches exceed industry standards
  • Specialized finish on key internal parts for superior corrosion resistance
  • Load tested to 150% of rated capacity with certificate
  • Meets ASME B30.16 standards
  • ISO 9001-2000 certified factory
  • NOTE: Custom Lifts are available in any length desired
  • Ask your local JET distributor for details!
  • Part # 101156
    Sold in qty's of 1
    Product type Chain Hoists
  • Rated Lifting Capacity : 11,000 lb
  • Standard Lift : 20'
  • Head Room : 23-5/8 Inch
  • Number of Falls : 2
  • Load Chain Diameter : 9.0mm
  • Force Req
  • to Lift Capacity : 83 lb
  • Length of Hand Chain Pulled to Lift Load 1' : 198'
  • A: 7-1/2 Inch
  • B: 11-1/8 Inch
  • C: 2-5/8 Inch
  • D: 2-1/2 Inch
  • E: 51mm
  • F: 60mm
  • G: 78mm
  • H: 23-5/8 Inch
