Chain Hoists KCH-2010L 2 Ton Kch Series Chain Hoist With Overload Protection Heavy Duty 101332 - Targa Tools
Chain Hoists JET KCH-2010L 2 Ton Kch Series Chain Hoist With Overload Protection Heavy Duty
Chain Hoists JET KCH-2010L 2 Ton Kch Series Chain Hoist With Overload Protection Heavy Duty

JET KCH-2010L ~ 2 Ton Kch Series Chain Hoist With Overload Protection Heavy Duty 101332

by JET
855.34 CAD

Ships in 5 days

2 Ton KCH Series Chain Hoist with Overload Protection - Heavy Duty

  • Equipped with an automatic overload protection device as standard equipment (up to 5 tons)
  • Device is factory preset to prevent serious overload of the hoist
  • Actuation is automatic, requiring no input from the operator
  • Triple Spur geared for efficient operation
  • Grade 100 load chain for greater strength
  • Exclusive premium grade, non-asbestos brake discs for longest life
  • Load tested to 150% of rated capacity with certificate
  • Meets ASME B30.16 standards
  • ISO 9001-2000 certified factory
  • NOTE: Custom Lifts are available in any length desired
  • Ask your local JET distributor for details!
    • Part # 101332
    Sold in qty's of 1
    Product type Chain Hoists
    Size 2-3/8 Inch
  • Rated Lifting Capacity : 4,400 lb
  • Standard Lift : 10'
  • Head Room : 14-3/4 Inch
  • Number of Falls : 1
  • Load Chain Diameter : 8.0mm
  • Force Req
  • to Lift Capacity : 79 lb
  • Length of Hand Chain Pulled to Lift Load 1' : 70'
  • A: 7-1/4 Inch
  • B: 8 Inch
  • C: 2-1/2 Inch
  • D: 1-3/8 Inch
  • E: 37mm
  • F: 46mm
  • G: 52mm
  • H: 14-3/4 Inch
