Chain Hoists KCH-0510 1/2 Ton 10' Lift Kch Series Chain Hoist Heavy Duty - Targa Tools
Chain Hoists Jet KCH-0510 1/2 Ton 10' Lift Kch Series Chain Hoist Heavy Duty
Chain Hoists Jet KCH-0510 1/2 Ton 10' Lift Kch Series Chain Hoist Heavy Duty

Jet KCH-0510 ~ 1/2 Ton 10' Lift Kch Series Chain Hoist Heavy Duty

by Jet
405.87 CAD

Ships in 5 days

1/2 Ton 10' Lift KCH Series Chain Hoist - Heavy Duty

  • Triple spur geared for efficient operation
  • Maintenance free sealed bearings reduce operator effort
  • Dual pawl Weston style brake with extra heavy pawl springs for safe reliable operation
  • Extra thick ratchet gear protects brake disc from contamination
  • Exclusive premium grade, non-asbestos brake discs for longest life
  • Grade 100 load chain for greater strength
  • Top and bottom safety hooks bend slowly to warn of overloads
  • Cast safety latches exceed industry standards
  • Specialized finish on key internal parts for superior corrosion resistance
  • Load tested to 150% of rated capacity with certificate
  • Meets ASME B30.16 standards
  • ISO 9001-2000 certified factory
  • NOTE: Custom Lifts are available in any length desired
  • Ask your local JET distributor for details!
    • Part # 101102
    Sold in qty's of 1
    Product type Chain Hoists
  • Rated Lifting Capacity : 1,100 lb
  • Standard Lift : 10'
  • Head Room : 11-1/4 Inch
  • Number of Falls : 1
  • Load Chain Diameter : 5.0mm
  • Force Req
  • to Lift Capacity : 51 lb
  • Length of Hand Chain Pulled to Lift Load 1' : 25'
  • A: 5-1/8 Inch
  • B: 5-1/2 Inch
  • C: 1-5
