Jet 120254 ~ 2 Ton Sbt Series Manual Trolley Heavy Duty

by Jet
705.89 CAD

Ships in 5 days

2 Ton SBT Series Manual Trolley - Heavy Duty

  • Load is moved by pulling on hoist load chain in direction of travel
  • Double sealed ball bearings for long life
  • Specially hardened steel wheels meet ANSI B30.11 specifications (Certificate included)
  • Specially designed integrated drop stops/bumpers take the load in the event of wheel failure and prevent wheels from contacting other trolleys on the track
  • Adjustable to fit various sizes of flanges and beams
  • Comes equipped for use on up to 8" beam widths
  • Can be installed or removed at any point along the track
  • Use on straight or curved H, I, W and S-beams
    • Part # 120254
    Sold in qty's of 1
    Product type Trolleys
  • Rated Capacity : 4,400 lb
  • I-Beam Flange Width (H) : 4 ? 8-1/32 Inch
  • Min
  • Curve Radius : 43 Inch
  • A: 13-29/32 Inch
  • B: 11-7/8 Inch
  • C: 10-15/16 Inch
  • D: 3-1/2 Inch
  • E: 1-1/8 Inch
  • F: 1/8 Inch
  • G: 6-1/16 Inch
